SPZL Drains effectively eliminate the drawbacks associated with condensate, a by-product of air compression. This includes its corrosive nature, contamination with pollutants, and potential oil content.
As condensate is present in all compressed air systems, continuous maintenance is crucial. However, by using SPZL Drains, you can efficiently remove moisture without any loss in air pressure.
Features
Energy Savings Maximum energy savings is achieved from the patented operation that guarantees true zero air loss.
Reliability An integrated sieve element concerns about dirty, Y-strainers, and extra maintenance giving you the highest level of reliability.
Intelligence The electronic control board and sensor ensure intelligent operation at all times with the ability to automatically clear clogs and debris.
Maintenance Maintenance time and costs are kept to an absolute minimum with a quick and easy procedure consisting of just one part.
Trustworthy You can rely on the global leader in condensate technology trusted by more equipment manufacturers than any other brand.
| SPZL Drain | 31 | 32 | 33 | 13 | 14 |
|---|---|---|---|---|---|
| Connection Size (NPT) | 1 x 1/2″ | 1 x 1/2″ | 3 x 1/2″ | 2 x 1/2″ | 3 x 3/4″ |
| Min./Max. Pressure (psig) | 12 / 232 | 12 / 232 | 12 / 232 | 12 / 232 | 12 / 232 |
| Compressor Flow Rate (scfm) | 100 | 225 | 500 | 1300 | 5400 |
| Dryer Flow Rate (scfm) | 200 | 450 | 1000 | 2600 | 10800 |
| Filter Flow Rate (scfm) | 1000 | 2250 | 5000 | 13000 | 54000 |
| Max Temperature | 140º F | 140º F | 140º F | 140º F | 140º F |
| Built In Sieve | √ | ||||
| Y Strainer | √ | √ |
